You can use several optional parameters in your Workbook to control the behaviour in multi-sheet workbooks. Please remember that all named ranges in data1.io must be defined on a sheet (and not workbook) level.

The most important

The following optional parameters can be defined to control multi-sheet workbooks:

• data1_ReadOnSheetChanged
• data1_SyncSheets_Read
• data1_SyncSheets_Write
• data1_CurrentSheetVisible

How to use the multi-sheet parameters

data1_ReadOnSheetChanged

Please be aware that a READ process is always executed when entering a sheet the first time after loading the workbook. This parameter rules the behaviour when re-entering a sheet after leaving it and then come back from another sheet.

0 = No refresh when re-entering the sheet

1 = Refresh (= READ) when re-entering the sheet

Simply add this new parameter to every page of your multi-sheet application and the sheet will be refreshed when you select a certain sheet of your workbook:

data1_SyncSheets_Read

Use this parameter to (optinally) sync the READ process for several sheets in your Template file. Simply enter the number of the sheets that should be part of the READ process and seperate them with a comma and space. Please note that you must also add the number of the current sheet if you want to keep the "normal" read behaviour for this sheet. We recommend to use the Excel function SHEET() in order to set the definitions dynamically.

Look at this example: the Excel Template file has 3 sheets. The first two sheets must always be read (and written) together since sheet 1 contains the parameters for the calculations in sheet 2. Simply add the named range with the content "1, 2" in the main sheet ...

... as well as in the Parameter sheet:

Please note:
For compatibility reasons the definition data1_CELLS01_SyncSheets_Read is also supported.

data1_SyncSheets_Write

Use this parameter to (optionally) sync the WRITE process for several sheets in your Template file. Works like the data1_SyncSheets_Read.

Please note that there is an addtional mechanism for the <SYSTEM Delta> Parameter: if you use in all sheets the same <SYSTEM Delta> Parameter then the delete process will be executed only once before writing the first sheet back (and not before every sheet). Nevertheless we recommend to use different <SYSTEM Delta> Parameters in every sheet since this is more intuitive.

Please note:
For compatibility reasons the definition data1_CELLS01_SyncSheets_Write is also supported.

data1_CurrentSheetVisible

1 = current sheet is visible

0 = current sheet is not visible

Can be used to setup a dynamic worksheet structure within the workbook depending on the currently logged in user ("object level security") and/or the currently selected element in the dimension tree.
